Heavy Duty Vertical Air Compressors

|

|

Compressor Spares

|

|

|

|

Compressor Spares

	We present specially constructed and designed single & two stage dry vacuum pumps. These vacuum pumps are highly efficient and possess an unmatched performance. These Dry Vacuum Pumps are Meant to acheive vacuum upto 750 mm of HG. Single & two stage Air Cooled Reciprocating, Single Acting Dry Vacuum Pumps, which are ideal for Liquid Transfer.Ceramic Industries, Paper handling, Lamination Plants etc.
The technical specifications of this compressor are :

MULTI STAGE COMPRESSORS (For high Pressure :17-70.30( kg/cm² )
MODEL	MOTOR		No.Of Cyl.	COMP. RPM	RECEIVER LTR	MAX. PRESSURE		PISTON DISPL CFM
MODEL	HP	KW	No.Of Cyl.	COMP. RPM	RECEIVER LTR	PSIG	KG/CM²	PISTON DISPL CFM
75 L/NL	25/30	18.5/22	1	600/725	300	125	8.75	131/160
85 L/NL	40	30	1	725	500	100	7.03	215
87 L/NL	50	37	1	650	1000	135	9.50	260
955 L/NL	40	30	1	675	1000	60	4.22	275
97 L/NL	60	45	1	650	1200	110	7.70	330
957 L/NL	60	45	1	650	1200	65	4.75	368

|

|

Compressor Spares

|

|

|

|

	Port Plates Frams & Outer
	Cross Head Pins And Bushing
	Inlet & Delivery Valves
	Valve Plates / Channels
	Piston Rods
	Pistons
	Spacer Plates

	Connection Roads
	Air Filter
	Cylinder
	Crank Shafts
	Gaskets
	Gland Packing Seals and Oil Wiper rings
	Piston rings and Rider Rings

	Single Stage Compressors
	Two Stage Compressors
	Multi Stages Compressor
	Heavy Duty Water Cooler Vertical Compressor
	Single & Two Stage Dry Vacuum Pump

	Air Receiver Tank
	Inter Coolers & After Coolers
	Screw Compressor Spares
